Coated Band Saw Blades

Coated Band Saw Blades

  • As the hardest material known to man, diamonds are capable of cutting any material, as well as alloys.
  • The unique properties of the backing materials developed for WIKUS are perfectly suited for standing up to the stress these extremely high cutting speeds cause.
  • Due to the rather unique applications of DIAGRIT®, we generally recommend that you contact us for advice on grain sizes to coordinate combinations of grain size and diameter of the blade to suit your application.
  • The backing material of our complete DIAGRIT® program will be adapted to stainless special steel.

  • WIKUS expands its portfolio of the coated band saw blades by the new product CUBOGRIT® which uses cubic boron nitride (CBN) as cutting material. Cubic boron nitride is the second hardest material known. Besides a high hardness and strength, also thermal and chemical resistance are its properties.
  • The unique properties of the backing materials developed for WIKUS are perfectly suited for standing up to the stress these extremely high cutting speeds cause.
  • In order to achieve an optimal and efficient result for your sawing applications,  we will be gladly prepared to advise you on the possible combinations regarding  the grain sizes, band saw blade dimensions as well as operating and basic  conditions of CUBOGRIT®. Our experts of the technical customer care will gladly get in contact with you.

  • Carbide coated band saw blades for cutting wire-reinforced tyres, composite  materials, case-hardened steels, glass fibre and graphite.
  • The extremely durable band edge is suitable for wet and dry cutting.

Diamond coated band saw blades

DIAGRIT® K

  • Product level 2
  • Band width 10 x 0.5 - 100 x 1.1mm
    Band width 3/8 x 0.020 - 4 x 0.042 Inch
  • Workpiece dimension small
  • Continuous diamond coating
To the product
Add to watchlistAdded to watchlist

DIAGRIT® K VA

  • Product level 2
  • Band width 13 x 0.5 - 100 x 1.1mm
    Band width 1/2 x 0.020 - 4 x 0.042 Inch
  • Workpiece dimension small
  • Continuous diamond coating
To the product
Add to watchlistAdded to watchlist

DIAGRIT® S

  • Product level 2
  • Band width 10 x 0.5 - 100 x 1.1mm
    Band width 3/8 x 0.020 - 4 x 0.042 Inch
  • Workpiece dimension medium
  • Segmented diamond coating
To the product
Add to watchlistAdded to watchlist

DIAGRIT® S VA

  • Product level 2
  • Band width 13 x 0.5 - 100 x 1.1mm
    Band width 1/2 x 0.020 - 4 x 0.042 Inch
  • Workpiece dimension medium
  • Segmented diamond coating
To the product
Add to watchlistAdded to watchlist

DIAGRIT® U

  • Product level 2
  • Band width 10 x 0.5 - 100 x 1.1mm
    Band width 3/8 x 0.020 - 4 x 0.042 Inch
  • Workpiece dimension large
  • Intermittent diamond coating
To the product
Add to watchlistAdded to watchlist

DIAGRIT® U VA

  • Product level 2
  • Band width 20 x 0.5 - 100 x 1.1mm
    Band width 3/4 x 0.020 - 4 x 0.042 Inch
  • Workpiece dimension large
  • Intermittent diamond coating
To the product
Add to watchlistAdded to watchlist

CBN-coated band saw blades

NEW

CUBOGRIT® K

  • Product level 2
  • Band width 10 x 0.5 - 100 x 1.1mm
    Band width 3/8 x 0.020 - 4 x 0.042 Inch
  • Workpiece dimension small
  • Continuous CBN-coating
To the product
Add to watchlistAdded to watchlist
NEW

CUBOGRIT® S

  • Product level 2
  • Band width 10 x 0.5 - 100 x 1.1mm
    Band width 3/8 x 0.020 - 4 x 0.042 Inch
  • Workpiece dimension medium
  • Segmented CBN-coating
To the product
Add to watchlistAdded to watchlist
NEW

CUBOGRIT® U

  • Product level 2
  • Band width 10 x 0.5 - 100 x 1.1mm
    Band width 3/8 x 0.020 - 4 x 0.042 Inch
  • Workpiece dimension large
  • Intermittent CBN-coating
To the product
Add to watchlistAdded to watchlist

Carbide coated band saw blades

TCGRIT® K

  • Product Level 2
  • Solid materials and profiles
  • Band width 6 x 0.5 - 32 x 1.1mm
    Band width 1/4 x 0.020 - 1-1/4 x 0.042 Inch
  • Workpiece dimension small
To the product
Add to watchlistAdded to watchlist

TCGRIT® U

  • Product Level 2
  • Solid materials and profiles
  • Band width 10 x 0.65 - 38 x 1.1mm
    Band width 3/8 x 0.025 - 1-1/2 x 0.042 Inch
  • Workpiece dimension large
To the product
Add to watchlistAdded to watchlist
Blade Selector

Your direct path to a solution

WIKUS offers the right product for every application.
Find the band saw blade you need for your sawing tasks in just a few simple steps.

Start Blade Selector
